Diamond
คุณสมบัติสินค้า:
SKU : Diamond
Fully Automatic Immuno Analyzer
หมวดหมู่ : 12. Lab Equipment , MicroDigital ,
แบรนด์ : MicroDigital (Korea)
Share
Diamond – Fully Automatic Immuno-Analyzer takes care of sample and reagent handling to well washing and optical measurement with a touch of a button.
Diamond is a convenient and accurate fully automated system specialized for CLIA(chemiluminescence immunoassay) and ELISA(enzyme-linked immunosorbent assay)
Feature
- Fully automated immunoassay system (luminescence, absorbance measurement)
- Open platform
- Compatible with conventional 96-well plates
- Quick and accurate control
- Minimized inter-well cross contamination through the use of disposable tips
- Accurate liquid handling
Specification
| General | |
| Sample Capacity | 96 Patient Sample Positions |
| Reagent Capacity | 9 Custom Reagent Positions |
| Test Tube | Standard 13, 16 mm diameter (Customizable) |
| No. of Microplate | 2 Microplate Positions |
| Barcode Reader | Optional |
| System Architecture | Universal Open Platform (Qualitative and Quantitative) |
| Sample Tray | Easy loading and unloading of samples |
| Dimension | 659 x 814 x 658 mm |
| Power | 100 – 240 V, 50 – 60 Hz |
| ELISA Reader Specification | |
| Dynamic Range | 0 – 3.0 OD |
| Photometer | 450, 630 nm (Optional: 405, 490, 550 nm) |
| Filter Slots | 6 |
| Precision | <1% CV (2.0 OD) |
| Accuracy | ±0.005 OD or 2.5% |
| CLIA Reader Specification | |
| Dynamic Range | Up to 7-log of dynamic range |
| Limit of Detection | 1 x 10-18 moles of ATP |
| Crosstalk | 3.0 x 10-5 |
| Washer | |
| Manifold Configuration | 8 Channels |
| Dispense-volume Range | 100 – 350 µl |
| Washing Tank | 2 External Washing Tanks (2.5L) and 1 Waste Tank (5L) with level sensing |
| Wash Cycle | 1 - ∞ (Customizable) |
| Residual Volume | <1 µl |
| Incubator | |
| Temperature Range | Up to 42℃ |
| Temperature Uniformity | ±1℃ |
| Shaking | Amplitude: 1 mm, Speed: Up to 800 RPM |
| Temperature Monitoring | Yes |
| Pipetting | |
| Aspiration Volume | ≥5 µl |
| Tip | Disposable |
| Serial Dilution | Yes |
| Replicates | Yes |
| Precision | <0.8% CV at 100 µl |
| Process Security | |
| Liquid-level Detection | Yes (Must use tips from MicroDigital) |
| Level-sensor System | Pressure Differential |
| Dispense-anomaly Detection | Yes |
| Tip Detection | Yes |
| Well-fill Verification | Yes |
| Alarms | Warning Message on PC Software |
| Software | |
| Operating Software | Diamond Software for PC |
| Work Protocols (Assays) | Unlimited |
| Data Processing | Quantitative and Qualitative |
| Access Level Control | Yes (Master, Manager, and Operator) |
| O/S | Windows® |
| Models | |
| Diamond E | System for ELISA |
| Diamond C | System for CLIA |
| Diamond M | System for ELISA & CLIA |
